90 pneumatic swing clamp with single side clamping + magnetic piston – swing clockwise when retracting – 80…100 swivel angle – 63mm bore – 18mm swing stroke / 50mm straight stroke / 68mm total stroke stroke – M12 x 1.75 female threaded rod-end – 2 x 1/4″ NPT threaded pneumatic ports – rated for +14…+158F / -10…+70C ambient – 50-100mm/s speed / 1.97-3.93″/s speed – hard anodized Aluminium body / hard Chrome-plated Carbon steel piston rod / Aluminium piston / standard Buna-N seals
-33%
SC63X50R Fabco Swing clamp Cylinders Pneumatic clamp
$212.95 Save:$105.00(33%)
Description
