90 pneumatic swing clamp with single side clamping + magnetic piston – swing counter-clockwise when retracting – 80…100 swivel angle – 63mm bore – 18mm swing stroke / 20mm straight stroke / 38mm total stroke stroke – M12 x 1.75 female threaded rod-end – 2 x 1/4″ NPT threaded pneumatic ports – rated for +14…+158F / -10…+70C ambient – 50-100mm/s speed / 1.97-3.93″/s speed – hard anodized Aluminium body / hard Chrome-plated Carbon steel piston rod / Aluminium piston / standard Buna-N seals
-37%
SC63X20L Fabco Swing clamp Cylinders Pneumatic clamp
$227.13 Save:$133.00(37%)
