90 pneumatic swing clamp with single side clamping + magnetic piston – swing counter-clockwise when retracting – 80…100 swivel angle – 40mm bore – 13mm swing stroke / 20mm straight stroke / 33mm total stroke stroke – M10 x 1.5 female threaded rod-end – 2 x 1/8″ BSPT threaded pneumatic ports – rated for +14…+158F / -10…+70C ambient – 50-100mm/s speed / 1.97-3.93″/s speed – hard anodized Aluminium body / hard Chrome-plated Carbon steel piston rod / Aluminium piston / standard Buna-N seals
-22%
SC40X20LP Fabco Swing clamp Cylinders Pneumatic clamp
$202.23 Save:$58.00(22%)
Description
