90 pneumatic swing clamp with single side clamping + magnetic piston – swing clockwise when retracting – 80…100 swivel angle – 25mm bore – 10mm swing stroke / 10mm straight stroke / 20mm total stroke stroke – M8 x 1.25 female threaded rod-end – 2 x M5 threaded pneumatic ports – rated for +14…+158F / -10…+70C ambient – 50-100mm/s speed / 1.97-3.93″/s speed – hard anodized Aluminium body / hard Chrome-plated Carbon steel piston rod / Aluminium piston / standard Buna-N seals
-35%
SC25X10R Fabco Swing clamp Cylinders Pneumatic clamp
$124.89 Save:$67.00(35%)
Description
